NT3200-32-MX Cashless Vending Machine - Product Information
Overview
Section titled “Overview”The NT3200-32-MX Cashless Vending Machine is a central control and payment terminal designed for self-service laundries.
It provides centralized operation and payment management for washing machines, dryers, and service systems through a fully cashless interface. The unit is optimized for modern unattended laundry environments where speed, simplicity, and contactless transactions are essential.
The system combines a large industrial touchscreen with integrated QR-code scanning, RFID card handling, receipt printing, and a contactless payment terminal.
Unlike traditional vending units, the NT3200-32-MX does not use coins or banknotes. All payments are processed digitally using contactless cards, RFID customer cards, or QR-code-based payment systems.
It is ideal for laundromats, apartment laundry rooms, student housing, hotels, hospitals, and other professional laundry installations.
Components
Section titled “Components”The device integrates the following components:
| No. | Component | Description |
|---|---|---|
| 1 | 32″ Capacitive Touch Display** | Main user interface, portrait orientation |
| 2 | Thermal Printer (80 mm)** | Silent receipt, ticket, and discount printing |
| 3 | Printer Lid Button** | Opens the printer compartment for paper replacement |
| 4 | QR-Code Reader** | Built-in scanner for QR codes and barcodes |
| 5 | RFID Reader / Writer** | Reads and writes RFID gift cards and service tokens |
| 6 | Card Terminal** | Contactless payment — IM30 or compatible |
| 7 | Side Opening Locks** | Secure access to internal components (2 locks) |
| 8 | Power Connector** | 220 V AC inlet |
| 9 | LAN Connector** | Ethernet network connection |
Key Features
Section titled “Key Features”- 32″ industrial capacitive touchscreen
- Full cashless payment concept
- Centralized control of washing machines and dryers
- Multi-language user interface
- QR-code and barcode scanning
- RFID card support (read / write)
- Receipt and voucher printing
- Contactless and contact payment support
- Backend integration for monitoring and pricing control
- Industrial wall-mounted secure housing
Payment Options
Section titled “Payment Options”The NT3200-32-MX supports a fully digital payment ecosystem:
- Contactless payment (NFC)
- Contact payment (chip cards)
- RFID customer cards
- RFID service cards
- Gift cards
- QR-code payments
- Mobile wallet integrations (depending on terminal configuration)
Since the system is fully cashless:
- No coin acceptor is required
- No banknote acceptor is required
- No change dispenser is required
This reduces service effort, maintenance complexity, and cash handling risks.
RFID System
Section titled “RFID System”The integrated RFID Reader / Writer supports:
- Customer loyalty cards
- Laundry access cards
- Gift cards
- Service and maintenance tokens
- Credit top-up operations
Functions include:
- Card reading
- Card writing
- Balance verification
- Service authorization
The system supports backend-managed customer card programs and discount logic.
Receipt & Ticket Printing
Section titled “Receipt & Ticket Printing”The integrated 80 mm thermal printer supports:
- Payment receipts
- Service receipts
- Promotional vouchers
- Discount tickets
- Maintenance printouts
- Test print functionality from backend
Additional features:
- Silent thermal printing
- Automatic receipt feed
- Quick paper replacement via front printer lid button
Uncollected receipts can be monitored through system diagnostics.
User Interaction
Section titled “User Interaction”Customers can:
- Select washing machines or dryers
- Choose washing programs
- View machine availability and pricing
- Pay using contactless card, RFID card, or QR-code
- Receive printed receipts
- Use customer loyalty cards
- Redeem gift cards or service tokens
The large portrait touchscreen ensures intuitive self-service operation and reduced queue times.
Technical Concept
Section titled “Technical Concept”The NT3200-32-MX is based on an industrial embedded control platform.
Communication interfaces include:
- Ethernet (LAN)
- RS485 (Modbus RTU)
- Relay control interfaces
- Payment terminal integration
- RFID integration
- QR scanner integration
Backend integration provides:
- Pricing management
- Device configuration
- Equipment monitoring
- Event logging
- Error diagnostics
- Remote maintenance
- Firmware management
- Printer test and service functions
An active internet connection is required for:
- Commissioning
- Monitoring
- Remote diagnostics
- Software updates
- Payment terminal communication
Housing & Installation
Section titled “Housing & Installation”Housing
Section titled “Housing”- Powder-coated steel industrial enclosure
- Wall-mounted construction
- Lockable side access panels
- Front service access for printer maintenance
- Reinforced industrial structure for public installations
The unit is designed for permanent indoor commercial operation.
Installation Requirements
Section titled “Installation Requirements”Electrical Connection
Section titled “Electrical Connection”Required:
- Power supply: 220 V AC
- Dedicated protected power line recommended
Network Connection
Section titled “Network Connection”Required:
- Ethernet cable with RJ45 connector
- Stable internet connection for backend and payment services
Mounting Requirements
Section titled “Mounting Requirements”- Secure wall mounting
- Stable wall structure suitable for industrial installation
- Service access space on both sides for lock opening
- Front clearance for user access and printer service
Recommended:
- Installation in dry indoor areas
- Protection from direct water exposure
- Controlled commercial environment
Dimensions
Section titled “Dimensions”| Parameter | Value |
|---|---|
| Overall Height | approx. 1700 mm |
| Overall Width | approx. 620 mm |
| Overall Depth | approx. 190 mm |
| Display Size | 32″ |
| Display Orientation | Portrait |
| Installation Type | Wall-mounted |
| Housing Type | Industrial steel enclosure |
| Front Panel Material | Powder-coated steel |
| Printer Type | 80 mm thermal printer |
| Power Supply | 220 V AC |
| Network | Ethernet (LAN) |
| Access Locks | 2 side opening locks |
The compact vertical design allows installation even in limited technical spaces while maintaining comfortable user interaction height and full front service accessibility.
Detailed engineering dimensions are available in the Technical Manual installation drawing.
Advantages
Section titled “Advantages”- Fully cashless operation
- Reduced maintenance costs
- No cash collection required
- Faster customer transactions
- Lower theft and vandalism risks
- Modern user experience
- Centralized backend management
- High reliability industrial design
- Simplified service access
Typical Installation Areas
Section titled “Typical Installation Areas”Recommended for:
- Self-service laundromats
- Apartment buildings
- Student residences
- Hotels
- Hospitals
- Staff laundries
- Fitness centers
- Campsites
- Commercial laundry rooms
